LMC6041IMX 供应商
-
LMC6041IMX
品牌：TI 封装/批号：原厂原装/22+ -
LMC6041IMX
品牌：NSC代理 封装/批号：SOP-8/新批号 -
LMC6041IMX
品牌：NS 封装/批号：SOP-8/23+ -
LMC6041IMX
品牌：NS/ELNAF 封装/批号：SOP8/1835+ -
LMC6041IMX/NOPB
品牌：TI(德州仪器) 封装/批号：SOIC-8/2022+
LMC6041IMX 属性参数
- 制造商：National Semiconductor (TI)
- 通道数量：1
- 共模抑制比（最小值）：62 dB
- 输入补偿电压：6 mV at 5 V
- 工作电源电压：5 V, 9 V, 12 V, 15 V
- 安装风格：SMD/SMT
- 封装 / 箱体：SOIC-8 Narrow
- 转换速度：0.02 V/us at 5 V
- 关闭：No
- 最大工作温度：+ 85 C
- 封装：Reel
- 最小工作温度：- 40 C
- 工厂包装数量：2500
- 电源电流：0.026 mA at 5 V
- Supply Voltage - Max：15.5 V
- Supply Voltage - Min：4.5 V
- 技术：CMOS
- 电压增益 dB：120 dB
产品特性
- Low Supply Current: 14 μA (Typ)
- Operates from 4.5V to 15.5V Single Supply
- Ultra Low Input Current: 2 fA (Typ)
- Rail-to-Rail Output Swing
- Input Common-Mode Range Includes Ground
产品概述
Ultra-low power consumption and low input-leakage current are the hallmarks of the
LMC6041. Providing input currents of only 2 fA typical, the LMC6041 can operate from a single
supply, has output swing extending to each supply rail, and an input voltage range that includes
ground.The LMC6041 is ideal for use in systems requiring ultra-low power consumption. In
addition, the insensitivity to latch-up, high output drive, and output swing to ground without
requiring external pull-down resistors make it ideal for single-supply battery-powered
systems.Other applications for the LMC6041 include bar code reader amplifiers, magnetic and
electric field detectors, and hand-held electrometers.This device is built with TI's advanced Double-Poly Silicon-Gate CMOS process.See the LMC6042 for a dual, and the LMC6044 for a quad amplifier with these
features.
LMC6041IMX 电路图
